DELL SD25TB5 Wired Thunderbolt 5 Black

Pro Thunderbolt 5 Smart Dock - SD25TB5

Reasons To Buy

Future-proof your productivity

Maximise your AI PC productivity on the industry’s first, and most powerful, Thunderbolt 5 smart dock, built for seamless multitasking using Gen AI tools across up to four 4K 120Hz displays. Featuring extended power range, this smart dock delivers up to 300W of power over a single USB-C cable to meet the demands of the highest performance AI PCs. Modern ports ensure a wide range of peripheral connectivity.

More manageable and secure

Elevate the IT management experience by directly managing your smart docks from the Dell Device Management Console – no PC connection or software required.

Most manageable commercial dock
Reduce IT efforts by scheduling updates during off-hours, while ensuring fleetwide firmware compliance and eliminating end user interruptions.

Most secure smart dock
Keep users working confidently with enterprise-grade WPA-3 192-bit encryption for secure Wi-Fi communication. Safeguard your sensitive data with tamper-resistant, hardware-based encryption built into your Dell Pro Smart Dock.

Effortless maintenance
Remotely configure, deploy and update Dell Pro Smart Docks over Wi-Fi without the user connecting to a PC.
Unlock out-of-band management on select Intel vPro® PCs with Intel® Active Management Technology (Intel® AMT) over Thunderbolt from the connected dock.

Connect your way

Configure your workspace to your liking with an ambidextrous USB-C cable that can be routed left or right.

Designed for sustainability

The Dell Pro Thunderbolt 5 Smart Dock is built with at least 65% post-consumer recycled materials and packaged with 100% recycled or renewable packaging.

Description

Conquer intense workloads with versatile Thunderbolt 5 smart dock, delivering up to 300W of future-ready power and remote management capabilities.

Specifications

Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	4
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	1
Host interface	Thunderbolt 5
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
HDMI ports quantity	1
HDMI version	2.1
DisplayPorts quantity	2
Microphone in	No
Headphone outputs	0
DC-in jack	Yes
Connectivity technology	Wired
USB Power Delivery up to	15 W
DisplayPort version	2.1
USB Type-C DisplayPort Alternate Mode	Yes
Thunderbolt 5 ports quantity	2
Network
Wake-on-LAN ready	Yes
Ethernet LAN	Yes
Ethernet LAN data rates	2500 Mbit/s
Ethernet LAN (RJ-45) ports	1
Performance
Maximum digital resolution	3840 x 2160 pixels
Product colour	Black
Card reader integrated	No
Cable lock slot	Yes
LED indicators	Power
Data transfer rate	1.25 Gbit/s
Cable lock slot type	Kensington, Noble
Number of storage drives supported	4
Maximum refresh rate	120 Hz
Technical details
Product colour	Black
Cable lock slot	Yes
Data transfer rate	1.25 Gbit/s
Total carbon footprint (kg of CO2e)	103
Storage
Card reader integrated	No
Power
Power supply	330 W
Software
Windows operating systems supported	Windows 10, Windows 11
Linux operating systems supported	Yes
Other operating systems supported	ChromeOS
Mobile operating systems supported	Yes
Indication
LED indicators	Power
Weight & dimensions
Weight	632 g
Width	90 mm
Depth	35.3 mm
Height	205 mm
Design
Windows operating systems supported	Windows 10, Windows 11
Product colour	Black
Cable lock slot	Yes
LED indicators	Power
Cable lock slot type	Kensington, Noble
Packaging data
Quantity per pack	1 pc(s)
Packaging content
Quick start guide	Yes
Cables included	AC
AC adapter included	Yes
Quantity per pack	1 pc(s)
Carbon footprint
Total carbon footprint (kg of CO2e)	103
PAIA version	GaBi version 1, 2025
Carbon emissions, energy usage (kg of CO2e)	38.728
Carbon emissions, manufacturing (kg of CO2e)	60.461
Carbon emissions, logistics (kg of CO2e)	1.957
Carbon emissions, end-of-life (kg of CO2e)	1.854
