Lenovo ThinkPad P16 Gen 2 Intel® Core™ i7 i7-14700HX Mobile workstation 40.6 cm (16") WQXGA 32 GB DDR5-SDRAM 1 TB SSD NVIDIA RTX 2000 Ada Wi-Fi 6E (802.11ax) Windows 11 Pro UK English Grey, Black

Intel Core i7-14700HX, 20C (8P + 12E)/28T, P-core 2.1/5.5GHz, E-core 1.5/3.9GHz, 33MB, 2x 16GB SO-DIMM DDR5-5600 Non-ECC, 1TB SSD M.2 2280 PCIe 4.0x4 NVMe Opal 2.0, 16" WQXGA (2560x1600) IPS 500nits 100% sRGB 165Hz Eyesafe, NVIDIA RTX 2000 Ada Generation 8GB, Intel Wi-Fi 6E AX211 11ax 2x2 + BT5.3, FHD 1080p + IR Hybrid with Privacy Shutter and Human Presence Detection, Windows 11 Pro

Key Features

• Intel Core i7-14700HX, 20C (8P + 12E)/28T, P-core 2.1/5.5GHz, E-core 1.5/3.9GHz, 33MB
• 16" WQXGA (2560x1600) IPS 500nits 100% sRGB 165Hz Eyesafe
• 2x 16GB SO-DIMM DDR5-5600 Non-ECC
• 1TB SSD M.2 2280 PCIe 4.0x4 NVMe Opal 2.0
• NVIDIA RTX 2000 Ada Generation 8GB
• Windows 11 Pro

Reasons To Buy

Configure it your way

For those that demand extra power, the ThinkPad P16 Gen 2 (16″ Intel) supports blazing-fast memory and high-performance storage. With power supply support of up to 230W, this mobile workstation can be configured to meet any need. And for the ultimate in connectivity, it has multiple ports for all your peripherals, as well as a range of WiFi options to keep you in the loop wherever work takes you.

It’s all in the details

The ThinkPad P16 Gen 2 (16″ Intel) has a backlit, spill-resistant keyboard with full a numeric keypad, making typing and number-crunching from anywhere easier, and safer. It also comes with Dolby Atmos® and Dolby Voice®, delivering superb audio. For extra precision, there's an OLED touchscreen display option, with a large aspect ratio offering more screen for your buck, and stylus pen support (sold separately). And with the optional FHD Hybrid IR camera, the human presence detection feature will alert you of potential shoulder-surfers.

Reliable & sustainable

Creators, designers, developers and other professionals can rest easy with the ThinkPad P16 Gen 2 (16″ Intel). It has been MIL-SPEC certified and passed more than 200 quality checks to ensure that it can run in the most extreme conditions. It also boasts an array of independent software vendor (ISV) certifications, ensuring that workload-optimized apps run seamlessly. And with its plastic-free packaging and recycled component content, this mobile workstation has earned its green stripes, too.See the complete list of ISV certifications

Secured by ThinkShield

On-the-go power requires no compromise in security, which is why the ThinkPad P16 Gen 2 (16″ Intel) is protected by ThinkShield. With features including discrete Trusted Platform Module (dTPM) to encrypt your data, a biometric fingerprint reader for simple one-touch login, and a self-healing BIOS that can restore earlier system settings, your mobile workstation and data are safe wherever you go.

Description

Portable power & performance unpacked
- Power-packed mobile workstation & mobile desktop in one
- Intel® Core™ HX Series processors with Intel vPro® options
- Supports NVIDIA® RTX™ & Intel® Arc™ discrete graphics
- Super-fast memory & storage, plus superb WiFi options
- Choice of stunning displays, including OLED touchscreen
- Legendary MIL-SPEC reliability, ISV-certified, ThinkShield security
- Made with recycled component content, plastic-free packaging

Specifications

Design
Colour name	Storm grey (top), villi black (bottom)
Product type	Mobile workstation
Housing material	Aluminium
Form factor	Clamshell
Product colour	Grey, Black
Display
HD type	WQXGA
Panel type	IPS
LED backlight	Yes
Display brightness	500 cd/m²
Contrast ratio (typical)	1200:1
Touchscreen	No
Display resolution	2560 x 1600 pixels
Display diagonal	40.6 cm (16")
Anti-glare screen	Yes
Maximum refresh rate	165 Hz
RGB colour space	sRGB
Colour gamut	100%
Native aspect ratio	16:10
Processor
Processor generation	Intel® Core™ i7 (14th gen)
Processor cache type	Smart Cache
Processor cache	33 MB
Processor model	i7-14700HX
Processor boost frequency	5.5 GHz
Processor cores	20
Processor threads	28
Motherboard chipset	Intel WM790
Processor manufacturer	Intel
Processor family	Intel® Core™ i7
Processor base power	55 W
Maximum turbo power	157 W
Efficient-core base frequency	1.5 GHz
Performance-core base frequency	2.1 GHz
Efficient-core Max Turbo Frequency	3.9 GHz
Performance-core Max Turbo Frequency	5.5 GHz
Performance cores	8
Efficient cores	12
Memory
Memory form factor	SO-DIMM
Internal memory	32 GB
Memory layout (slots x size)	2 x 16 GB
Internal memory type	DDR5-SDRAM
Memory clock speed	5600 MHz
Memory slots	4x SO-DIMM
Maximum internal memory	192 GB
Memory channels	Dual-channel
Non-ECC	Yes
Storage
SSD form factor	M.2
Storage media	SSD
Optical drive type	No
Number of SSDs installed	1
SSD capacity	1 TB
SSD interface	PCI Express 4.0
Card reader integrated	Yes
Compatible memory cards	SD
Total storage capacity	1 TB
Total SSDs capacity	1 TB
NVMe	Yes
Graphics
Discrete graphics card	Yes
Discrete graphics card memory	8 GB
On-board graphics card family	Intel® UHD Graphics
On-board graphics card	Yes
On-board graphics card model	Intel® UHD Graphics
Discrete graphics card model	NVIDIA RTX 2000 Ada
Discrete graphics memory type	GDDR6
Discrete GPU manufacturer	NVIDIA
On-board GPU manufacturer	Intel
Audio
Audio chip	Realtek ALC3306
Number of microphones	2
Audio system	Dolby Atmos
Number of built-in speakers	2
Speaker power	2 W
Built-in microphone	Yes
Camera
Front camera	Yes
Front camera resolution	1920 x 1080 pixels
Privacy camera	Yes
Privacy type	Privacy shutter
Front camera HD type	Full HD
Infrared (IR) camera	Yes
Windows Hello	Yes
Optical drive
Optical drive type	No
Network
Mobile network connection	No
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
WLAN controller model	Intel Wi-Fi 6E AX211
Near Field Communication (NFC)	No
Wi-Fi standards	Wi-Fi 6E (802.11ax)
Ethernet LAN	No
Bluetooth	Yes
Bluetooth version	5.3
WWAN	Upgradable
Antenna type	2x2
WLAN controller manufacturer	Intel
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	1
USB Type-C DisplayPort Alternate Mode	Yes
USB Sleep-and-Charge ports	1
USB Sleep-and-Charge	Yes
USB 2.0 ports quantity	0
HDMI ports quantity	1
HDMI version	2.1
Combo headphone/mic port	Yes
USB Power Delivery (USB PD)	Yes
Thunderbolt 4 ports quantity	2
Intel® Thunderbolt 4	Yes
Performance
Motherboard chipset	Intel WM790
Keyboard
Pointing device	ThinkPad UltraNav
Numeric keypad	Yes
Spill-resistant keyboard	Yes
Keyboard backlit	Yes
Keyboard language	UK English
Software
Operating system language	English
Operating system architecture	64-bit
Operating system installed	Windows 11 Pro
Technical details
Housing material	Aluminium
Form factor	Clamshell
Product colour	Grey, Black
Discrete graphics card memory	8 GB
Sustainability compliance	Yes
Battery
Battery technology	Lithium Polymer (LiPo)
Battery capacity	94 Wh
Fast charging	Yes
Power
AC adapter power	170 W
AC adapter frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
USB Power Delivery (USB PD)	Yes
Security
Password protection	Yes
Cable lock slot type	Kensington
Trusted Platform Module (TPM)	Yes
Password protection type	BIOS, Power on, Supervisor, SSD
Fingerprint reader	Yes
Cable lock slot	Yes
Windows Hello	Yes
Smart card reader	Yes
Trusted Platform Module (TPM) version	2.0
Operational conditions
Operating temperature (T-T)	5 - 35 °C
Storage temperature (T-T)	5 - 43 °C
Operating relative humidity (H-H)	8 - 95%
Storage relative humidity (H-H)	5 - 95%
Maximum shipping altitude	3048 m
Certificates
Certification	MIL-STD-810H
Sustainability
Sustainability compliance	Yes
Weight & dimensions
Width	364 mm
Depth	266 mm
Height	30.2 mm
Weight	2.95 kg
Other features
WLAN controller model	Intel Wi-Fi 6E AX211
On-board graphics card	Yes
Audio system	Dolby Atmos
Maximum shipping altitude	3048 m
Anti-glare screen	Yes
